A516 Grade 55 Steel Plate

It is composed of 0.04% S, 0.26% C, 0.15-0.30% Si, 0.60-1.20% Mn, 0.035% P, and Fe.
Availability:

PDF Export

facebook sharing button
twitter sharing button
whatsapp sharing button
wechat sharing button
sharethis sharing button
  • A516 Grade 55

Specification for Boiler Quality Steel Plates & Sheets

Thickness3mm to 200mm
Width1250mm to 4000mm
LengthUp to 20,000mm
CertificationDUAL CERTIFICATION [SA 516 GR. 60 / 70]
TRIPLE CERTIFICATION. [SA 516 GR. 60 / 65 / 70]
IBR AND NON IBR



Chemical Analysis for Boiler Quality Steel Plates

CMn

P
max

S maxSi max

t < 12.5
mm
12.5mm < t =50mm50mm < t ≤ 100mm100mm < t ≤ 200mmt < 200
mm
t < 12.5
mm
t >12s.5
mm
A516 Grade 550.180.20.220.240.2606-090.55-0.980.0350.0350.15-0.4
A516 Grade 600.210.230.250.270.2706-090.85-1.20.0350.0350.15-0.4
A516 Grade 650.240.260.280.290.290.85-1.20.85-1.20.0350.0350.15-0.4
A516 Grade 700.270.280.30.310.310.85-1.20.85-1.20.0350.0350.15-0.4



Tensile Requirements for Boiler Quality Steel Plates


Tensile Strength (ksi)Tensile Strength (MPa)Yield Strength (ksi)Yield Strength (MPa)Elongation in 200mm(%)Elongation in 50mm(%)
A516 Grade 5555-75380-515302052327
A516 Grade 6060-80415-550322202125
A516 Grade 6565-85450-585352401923
A516 Grade 7070-90485-620382601721



Applications

- Aerospace Industry
- Nuclear Power Plant Industry
- Chemical Industry
- Refineries Industry
- Paper Industry
